Roxy 40 SCSR | Self-Contained Self-Rescuer
Breathe Easy. Escape Safely.
Roxy 40 SCSR is a compact, belt-worn
self-contained self-rescuer for underground mining emergencies. Provides up to 40 minutes of breathable
air for rapid, reliable escape.
The Roxy 40 is a Self-Contained Self-Rescuer (SCSR) designed for underground mining and emergency escape situations. It provides up to 40 minutes of breathing air using chemical oxygen generation. The unit is robust, lightweight, and belt-worn, giving miners immediate access during fire, gas, or smoke emergencies.
The value to the customer lies in its ability to enhance miner safety and provide peace of mind, enabling workers to escape hazardous environments quickly and reliably, reducing the risk of serious injury or fatalities in emergency situations.
Features
40-Minute Protection
Provides up to 40 minutes of breathable air.
Belt-Worn Convenience
Lightweight and compact for immediate access.
Chemical Oxygen Generation
Reliable supply without external power.
Rugged Construction
Built to withstand harsh mining environments.
Easy Activation
Simple, intuitive operation in emergencies.
Compliance Ready
Meets international mining safety standards.
Why Mines Choose the Roxy 40 SCSR
Breathing Safety when every second counts. Underground emergencies demand immediate action — smoke, fire, or toxic gas can spread in moments. The Roxy 40 isn’t just a safety device; it’s a life-saving tool engineered to perform under the harshest conditions.
Its compact, belt-worn design ensures miners have instant access to breathable oxygen, giving them the crucial time needed to escape safely. With reliable chemical oxygen generation and proven durability, mines trust the Roxy 40 to protect lives, ensure compliance, and provide peace of mind.
Integrated with SmartMine monitoring, your safety team can track issued SCSRs and ensure readiness at all times.
Bottom line: Higher safety, faster emergency response, compliance assurance, and peace of mind.
Engineering Features
Provides up to 40 minutes of breathable oxygen
Lightweight, belt-worn design for immediate access
Chemical oxygen generation—no external power needed
Robust, impact-resistant casing
Simple activation and donning process
Designed for underground mining and confined spaces
Technical Specifications
| <strong>PARAMETER</strong> | <strong>VALUE / UNIT</strong> |
|---|---|
| Protection Time | Up to 40 min |
| Weight | Lightweight |
| Oxygen Generation | Chemical |
| Activation | Manual |
| Mounting | Belt-worn |
Information
| Rate | ||
|---|---|---|
| 35 L/min | 50 L/min | |
| Normalized time of protective action, minutes, not less | 40 | 20 |
| Breathing resistance, kPa, not more | 1,0 | 1,5 |
| The content of CO, in the inhaled air, %, not more | 3% | |
| Temperature of the inhaled air, oC, not more | 50 | 60 |
| Temperature on the surface of the case, oC, not more | 120 | 140 |
| Temperature on the surface of the cartridge, oC, not more | 145 | 165 |
| Weight, kg | 2,25±0,1 | |
| Dimensions | mm 203±2 (height) 202±2 (length) 116±2 (width) | |
| Life of unit, not less than, years | 10 | |
